Product Details:
Payment & Shipping Terms:
|
| Product Model: | JHX-6080 | Working Area(mm): | 600x800 |
|---|---|---|---|
| Marking Area(mm): | ≦5 | Marking Speed: | 0-120000mm\min |
| Marking Repeat Precision: | ≤±0.01mm | Marking Line Width: | ±0.01mm |
| Pulse Frequency: | ≤100KHZ | Working Voltage: | 220v±10%, 50-60HZ |
| High Light: | galvo laser cutting machine,galvo laser marking machine,Cloth Textile Galvo Laser Engraver |
||
CO2 RF Tube Flying Laser Engraving Marking Machine For cloth textile JHX-6080
DESCRIPTION
CO2 laser is a gas laser with CO2 as laser medium and wavelength near 10.6um. When high-voltage is added to electrodes, discharging through the cavity will excite CO2 molecules and produce 10.6um laser radiation. After amplifying its energy, the discharged laser can be directed for processing material.
Features
High speed scanning galvanometer, high-performance imported laser, precision accurate, stable performance, quick speed, high precision of elevating work platform, realize the long time stable and reliable operation, simple operation, easy to use, legible.
Control software adopts Windows engineering interface, compatible with Coreldraw, AutoCAD, Photoshop, and other graphical output file format, such as PLT, PCX, DXF, BMP, etc. Also directly use SHX, TIF word stock, through the computer random design graphics.
Material & Application
Leather, cloth, wood, paper, acylic, epoxide resin, polyester resin and such non-metal materials.
All kinds of metal and alloy; Rubber porcelain film, stone, silicon; epoxies resin and ABS etc non-metal.
Technical specification
| Product model | JHX-6080 |
| Laser Type | Imported metal encapsulating RF CO2 laser |
| Laser Power | Option: 100W/150W |
| Working Area(mm) | 600x800 |
| Marking Area(mm) | ≦5 |
| Cooling | Water-cooling |
| Marking speed | 0-120000mmmin |
| Marking Repeat Precision | ≤±0.01mm |
| Marking line width | ±0.01mm |
| Min character | 0.30mm |
| Auxiliaries | Wind pump, Wind pipe etc |
| Pulse Frequency | ≤100KHZ |
| Working voltage | 220v±10%, 50-60HZ |
APPLICATION VIDEO
COLLOCATION
CO2 RF Tube Flying Laser Engraving Marking
