| Product Model: | JHX-160100S | Laser Power: | Option: 80W/100W/130W/150W |
|---|---|---|---|
| Working Area(mm): | 1600×1000 | Software: | JHX Professional Controlling Software |
| Cooling: | Water-cooling | Positioning Accuracy: | ≦±0.01mm |
| Auxiliaries: | Wind Pump, Wind Pipe Etc | ||
| High Light: | co2 laser cutting machine,co2 laser marking machine,Plush Toy Laser Cutting Engraving Machine |
||
High Speed Laser Plush Toy CO2 laser Machine stuffed toys soft toys JHX-160100S
DESCRIPTION
JHX Laser developed a series of laser machines and solutions for stuffed toys and craftwork slippers industries. Using advanced CNC operating platform with non-contact processing method, not only ensures high speed and stability of the equipment. But also ensures smooth and accurate cutting edge. It is especially precise in cutting of eyes, noses, ears and other parts, completely solving the problems of high cost, long process-cycle, low accuracy, easy fraying, pollution of toy part pieces with conventional tool cutting and electrically heated cutting technology.
Cutting Control Technology with Digital Movable Multi-head for Toys Industry:
JHX Laser’s patent multi-head laser control technology not only ensures uniformity of laser head power configuration, but also can adjust distance between laser heads according to the width of the processed materials. On the precondition of most saving fabric, the software ensures the maximum amount of laser heads on work and greatly improves working efficiency. Meanwhile, the software integrates the professional characteristics of toy industry. It is allocated with embedded processing nesting software. The software saves energy cost and fabric wastage to the maximum, automatically controls processing direction about whether from the left or right side of the fabric and calculates output of the products, which makes it convenient for the clients to control processing.
Features
1. can engrave on image also it can engrave on vector graphics, the engraving accuracy can be setting.
2. System log can count working time and process time.
3. Stable operating, high Speed cutting speed, flex and smart process way.
Material & Application
All kind non-metal materials, such as fabric, leather, wool, wood, plastic, rubber, acrylic, crystal, bamboo and etc.
Garment, textile, leather and fabric toy industry, computer embroidery, applique work, leather shoes, lighting, hollowing industry, House ornamentation, cloth art, bag industry; craftwork, model, advertisement industry.
Technical specification
| Model | JHX-160100S |
| Laser Type | Hermetic and detached CO2 laser tube |
| Laser Power | 80W/100W/130W/150W |
| Cutting speed | 0-50000mmmin |
| Working Area(mm) | 1600×1000 |
| Cooling | Water-cooling |
| software | JHX professional controlling software |
| Positioning accuracy | ≤±0.01mm |
| Cutting power control | Fine tuning possible |
| Working Voltage | 220V±10%, 50-60HZ |
| Moving system | Imported servo system |
| Data Format | AI,BMP,PLT,DXF,DST |
| Auxiliaries | Wind pump, Wind pipe etc |
APPLICATION VIDEO
COLLOCATION
Push toys, dolls, curtains, bedsheets, embroideries Laser cutter
