Product Details:
Payment & Shipping Terms:
|
| Product Model: | JHX-6060 | Laser Type: | Hermetic And Detached CO2 Laser Tube |
|---|---|---|---|
| Laser Power: | Option: 100W/150W | Working Area(mm): | 600x600 |
| Marking Area(mm): | ≦5 | Cooling: | Water-cooling |
| Marking Speed: | 0-120000mm\min | WMin Character: | 0.30mm |
| High Light: | galvo laser cutting machine,galvo laser marking machine,High Precision Co2 Galvo Laser Machine |
||
Large Co2 Galvo Laser Machine For Invitation Card Textile JHX-6060
DESCRIPTION
Galvo Laser Systems use high powered lasers to vaporize material in the laser beam path; eliminating hand labor and other complicated extraction methods needed for small part scrap removal. Galvo Laser Systems use mirror angles to reposition the laser beam in different directions; making the process relatively quick.
Co2 laser marking machine adopts imported CO2 RF laser generator and high speed galvo scanner system. With high quality optic devices, high stability laser generator,full automatic control system.
The machine system working with high precision and fast speed, very stable performance,can work continuously for a long time and can be applied directly in large quantities of online processing lines.
Features
1. CO2 laser marking machine ,adopted the EFR /RECI laser tube , 60w/80w 100w can optional , long working life , with fast marking speed .
2. Adopting Water cooling , you can choose water pump or water chiller , it can Protection water cooling system.
3. Stable structure, little vibration during work. High precision with repetition as tiny as 0.003mm.
4. Low power consumption: low cost, only 0.1-0.2kw per hour.Perfect performance, 24 hours continuous working ability.
5. Imported high speed galvanometer scanner. (China brand optional),For long-term consideration, the cost is much lower than other laser marking machine.
6. Powerful function, friendly interface, to meet the various technical personnel operating habits.
Material & Application
| PVC, pipe, wire insulation, seals |
| ABS, electrical appliances shell, daily necessities |
| Acrylic, transparent material, instrument case |
Bulletproof plastic, high impact requirements of the transparent products |
| Unsaturated polyester, paint, ornament, sheet, button |
| Polyurethane, soles, artificial leather, paint |
| Epoxy, electronic components, insulation, insulation |
| Glass, glass surface |
Technical specification
| Product model | JHX-2020 |
| Laser Type | Hermetic and detached CO2 laser tube |
| Laser Power | Option: 100W/150W |
| Working Area(mm) | 200x200 |
| Marking Area(mm) | ≦5 |
| Cooling | Water-cooling |
| Marking speed | 0-120000mm/min |
| Marking Repeat Precision | ≤±0.01mm |
| Marking line width | ±0.01mm |
| Min character | 0.30mm |
| Auxiliaries | Wind pump, Wind pipe etc |
| Pulse Frequency | ≤100KHZ |
| Working voltage | 220v±10%, 50-60HZ |
APPLICATION VIDEO
COLLOCATION
Large Co2 Galvo Laser Machine
